Configuring System Settings 25
5 Configuring System Settings
Configuring Visual & Audio Parameters 5.1
Adjust the screen’s display effect and the Signage volume.
In main menu, select Settings > Audiovisual Adjustment. Step 1
The Audiovisual Adjustment interface is displayed. See Figure 5-1.
The audiovisual adjustment interface Figure 5-1
Configure visual & audio parameters. See Table 5-1 for details. Step 2
Table 5-1 Description of visual & audio parameters
Item
Description
Image Effect
Adjust the display image’s chroma, contrast and saturation. The default values
are recommended.
Backlight
Brightness
Adjust the display’s background brightness manually or in an automatic way.
1. Click Backlight Brightness to adjust its value.
It’s set by default that the auto adjustment of background brightness is
enabled and the background brightness will be adjusted according to
the surrounding lighting condition.
You can drag the brightness bar to adjust the background brightness
manually and the auto adjustment of background brightness is
disabled in the meanwhile.
2. Click OK to finish configuration.
Output
Resolution
Select resolution of the screen under work from 1080P 60Hz, 1080P 50Hz,
720P 60Hz and 720P 50Hz.
Screen
Rotation
Rotate your screen and select from Rotate 90°, Rotate 180° and Rotate 270°.
