Appearance 4
Components 2.2
Components (43, 49, 55 and 65 inches) Figure 2-5
Table 2-1 Components description
Name
Description
Wi-Fi antenna
Receives Wi-Fi signals and connect the Signage to the network in
a wireless way.
TFT LCD display
Shows information.
Signal indicator of
remote control
Receives signals from remote control.
Light sensor
Adjusts screen brightness automatically according to the
environment lighting condition.
Indicator of the
Signage status
Indicates the Signages working status.
(When the indicator is) off: You havent connected the
Signage to power source.
Flashing in red: You are booting up the Signage.
On and in blue: You have booted up the Signage or you have
only turned off the screen.
On and in red: You have connected the Signage to power
source and turned off the Signage.
Speaker
Plays sound.
Heat emission
hole
Emits heat.
Ports 2.3
To view the main boards ports, use the given key to unlock the rear panel. For ports details,
see Figure 2-6 and Table 2-2.
