Installation 6
3 Installation
Unpacking the Box 3.1
Refer to the following checklist and check the package. If you find device damage or
component loss, contact the after-sales service.
Check
Sequence
Check Item
Check Content
1
Overall
packing
Appearance
No obvious damage.
Packing
Not distorted or broken.
Component
No missing.
2
Pedestal
Model on label
Matches purchase order.
Label
Not torn up.
Do not tear up or throw away the labels;
otherwise the warranty services are not
ensured. You need to provide the serial
number of the product when calling the
after-sales service.
3
Screen
Appearance
No obvious damage.
Data cable, power
line
No loose connection.
Contact the after-sale service staff
immediately if these cables or lines are
loose.
Installation 3.2
3.2.1 Attaching Signage Main Body to Pedestal
Align the Signage main body’s holes to those on the pedestal, and then fasten the Step 1
screws. See Figure 3-1.
Attaching Signage main body Figure 3-1
