Local Configurations 100
Click the AUX Config icon to open
the PTZ functions settings interface.
Click the Enter Menu icon to open
the MENU OPERATION interface.
Table 5-22
5.4.3 Configuring PTZ Functions
5.4.3.1 Configuring Presets
On the Expanded PTZ Control Panel, click . Step 1
The Preset interface is displayed. See Figure 5-59.
Figure 5-59
Click the direction arrows to the required position. Step 2
In the Preset box, enter the value to represent the required position. Step 3
Click Setting to complete the preset settings. Step 4
5.4.3.2 Configuring Tours
On the Expanded PTZ Control Panel, click . Step 1
The PTZ interface is displayed.
Click the Tour tab. Step 2
The Tour tab is displayed. See Figure 5-60.
