Dahua DH-XVR5108C-X User Manual

Getting Started 5
2.2.2 DH-XVR7104E-4KL-X/DH-XVR7108E-4KL-X/DH-XVR7104E-
4KL-B-X/ DH-XVR7108E-4KL-B-X
2.2.2.1 Installing Battery
The battery is only provided with some models.
1. Pull the battery cable through the hole.
2. Connect to the cable into the port.
2.2.2.2 Installing HDD
Skip step 6 if the battery is not equipped with the model you purchased.
1. Remove the screws to take
off the cover.
2. Remove the screws to take
off the bracket.
3. Put the HDD onto the
bracket.
4. Match the holes on the
bracket with the screw
holes on HDD.
5. Use screws to fix the HDD
onto the bracket.
6. (Optional) Pull the
battery cable through
the hole to connect into
the cable port.
