Dahua Lite NVR2104-4KS2 User Manual

88
Please refer to the following sheet for detailed information.
Icon
Name
Function
Power input
socket.
Power socket. Input DC12V/2A.
Network port
10M/100Mbps self-adaptive Ethernet port. Connect to
the network cable.
USB2.0 port
USB2.0 port. Connect to mouse, USB storage device,
and etc.
HDMI
High Definition
Media Interface
High definition audio and video signal output port. It
transmits uncompressed high definition video and
multiple-channel data to the HDMI port of the display
device. HDMI version is 1.4.
VGA
VGA video output
port
VGA video output port. Output analog video signal. It
can connect to the monitor to view analog video.
GND
Ground end
Wireless AP
Support wireless hotspot function. Use WIFI to
connect to the network camera when there is a
hotspot.
2.2.6 Beneficio 1U (S2)/ Beneficio 4K 1U(S2) Series
The general series rear panel is shown as below. See Figure 2-27.
Figure 2-27
The 4 PoE ports series rear panel is shown as below. See Figure 2-28.
Figure 2-28
The 8 PoE ports series rear panel is shown as below. See Figure 2-29.
Figure 2-29
