2.2.8 Professional 4K 1U/ Professional 4K 1U with 8 PoE ports/ Professional 4K 1U
with 16 PoE ports/4K 1U (S2) with 24 PoE Ports/4K 1U (S2E) with 16 PoE ports
Series
The professional 4K 1U series rear panel is shown as below. See Figure 2-35.
Figure 2-35
The professional 4K 1U with 8 PoE ports rear panel is shown as below. See Figure 2-36.
Figure 2-36
The professional 4K 1U with 16 PoE ports rear panel is shown as below. See Figure 2-37.
Figure 2-37
The 4K 1U (S2) with 24 PoE ports series rear panel is shown as below. See Figure 2-38.
Figure 2-38
The 4K 1U (S2E) with 16 PoE ports series rear panel is shown as below. See Figure 2-39.
Figure 2-39
Please refer to the following sheet for detailed information.
Icon
Port Name
Function
