Dahua VTH5221 Series User Manual

Interface Operation 47
Figure 6-10
Press to enable alarm output function, and the icon becomes . Step 4
6.2.4 Mode Setting
Set area on/off status under different modes.
Area mode can be set only in disarm status.
Press [Setting]. Step 1
The system pops up “Password” prompt box.
Input login password and press [OK]. Step 2
Default login password is 123456. Please refer to “6.2.6.3 Password Setting“ for
details.
Press [Mode]. Step 3
The system displays “Mode” interface, as shown in Figure 6-11.

Dahua VTH5221 Series Specifications

General

Alarm Output	1 channel
Display	7-inch touch screen
Resolution	1024 x 600 pixels
Connectivity	Ethernet
Power Supply	DC 12V
Operation Method	Touch buttons
Audio Input	Built-in microphone
Network Protocol	TCP/IP
Video Compression	H.264
Operating Temperature	-10°C to +55°C
Operating Humidity	10%–95% (RH)
