Interface Operation 49
Figure 6-12
Input VTH no. in the corresponding forward mode, press to enable the Step 4
forward function. Please refer to Table 6-4 for details.
Parameter
Description
Always
All incoming calls will be forwarded to preset number immediately.
Busy
When the user is busy, incoming call from the third party will be
forwarded to preset number. If No Answer is not set, when the user
refuses to answer, the incoming call will be deemed as busy
forwarding.
No Answer
If no one answers after VTH ring time, the incoming call will be
forwarded to preset number.
Set VTH ring time at Setting > Ring > Other interface.
Table 6-4
To forward to an user of another building or unit, the forward number is Building +
Unit + VTH room number. For example, input 0101101 for 101 of Unit 1, Building
1.
To forward to an user of the same unit, the forward number is VTH room number.
Press [OK] to save settings. Step 5
6.2.6 General Setting
Set VTH time, display, password and others.
6.2.6.1 Time Setting
Set VTH system time, time zone and DST.

Table of Contents

Other manuals for Dahua VTH5221 Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua VTH5221 Series and is the answer not in the manual?

Dahua VTH5221 Series Specifications

General IconGeneral
Alarm Output1 channel
Display7-inch touch screen
Resolution1024 x 600 pixels
ConnectivityEthernet
Power SupplyDC 12V
Operation MethodTouch buttons
Audio InputBuilt-in microphone
Network ProtocolTCP/IP
Video CompressionH.264
Operating Temperature-10°C to +55°C
Operating Humidity10%–95% (RH)
