Dahua VTH5321GW-W User Manual

6
Screw hole distances and diameters [mm] Figure 2-4
Drill two screw holes in the wall according to holes on the bracket. Step 1
Put anchor bolts into the screw holes. Step 2
Fix the bracket on the wall with screws. Step 3
Connect cables (power cable, network cables, and more). Step 4
Hang the indoor monitor on the bracket. Step 5
The installation is completed.

Dahua VTH5321GW-W Specifications

General

Brand	Dahua
Model	VTH5321GW-W
Category	Monitor
Language	English
