ASY‑206‑077
2
1.Cautionsofinstallationandwiring.
Thosewhohaveaprofessionalskillneedtoperforminstallationandwiringafterconsultingahandling
coveringletter.And,pleasefollowthefollowingnotes.
z Thereisnofunctionthatchecksthebalanceofphase‑sequencedetectionandthree‑phasevoltageseach. 
Pleaseinquireseparately.
z Pleasebesuretoseparatewiringbythestrongelectricside,andthewiringbythelightelectricalside.
Pleasecarryoutconsideration(malfunctionprevention)toanoise.
z PleasebesuretogroundgroundingterminalE(terminal9)inordertoincreasetheshieldeffect.

z Pleaseperformconnectionaftercheckingschematics.
z Unsuitableconnectioncausestroubleofapparatus,andafireandanelectricshock.
z Thepowermustbeturnedoffbeforeinstallationandwiringworks.Itbecomesthecausalityofthe
trouble,burnout,andfireofanelectricshockandapparatus.
z Forelectricshockprevention,afterwiringiscompleted,pleaseinstallaterminalcover.
2.Operationmethod
Specialknowledgeisrequiredtousethisproduct.Pleasecarryouttherighthandlingwithreferenceto
aninstructionmanual.
z Pleasedonottouchequipmentduringoperation.Itbecomesthefactorthatcausesamalfunction.
z Pleaseapplybusvoltageafterestablishingvoltage(AC90to125V).Sincethepowersupplyofequipment
isshared,ifavoltageupsurgeisdonegradually,itwilldoamalfunctionbythepowersupplyunstable
region.
z Pleasemakeacinput(busvoltage,generatorvoltage)intonon‑voltageaftertheendofsynchronouscontrol.
And,pleaseturnOFFacontrolinput(automaticsynchronousstart,manualsynchronousstart).
However,althoughacinputisnoprobleminthestateofvoltageapplying,pleasegivebusvoltageas
variationwithintherange(AC90to125V).
ASLOWsideinputdesignatinginputisnoproblemwithON.
z Theswitchingcapacityofacontroloutput(opticalMOS‑FETrelay)isDC100V,50mAorDC24V,100mA.
Pleaseinstalltheelementthatabsorbsthereverseinducedvoltagethatitgeneratesatthetimeof
switchinginthecoiloftherelayusefortheoutsideofthisproduct.
z Ifitisthewaveformthatisdoinginvertercontrol,andawaveformwithalargedistortionrate,
frequencymeasurementandphasedifferencemeasurementmaybecomeunusual.

z Inputterminalandoutputterminaliswithaterminalcover.Pleaseinstallaterminalcoverafterwiring.
z Pleasedonottouchaterminalduringoperation.Thereisapossibilityofreceivinganelectricshock.
z Pleasedonotapplyavoltagesignal,becausecontrolsignalinputisanon‑voltagecontact.
Thereisapossibilitythatapparatusmaybedamagedbyfire.And,ifitusesanoutsiderelayfor
controlsignalinput,pleaseusetherelaywhoseminimumloadsatisfiesswitchingvoltageandcurrent
DC12V,10mA.
3.Setting
Pleasesetupwithreferencetoaninstructionmanual.And,pleasefollowthefollowingnotes.
z Pleasecloseaswitchcoverduringoperationandaftersettingup.
z Pleasesetupthenextstate.Non‑voltage(allarenon‑voltageofbusinput,generatorinput),or
controlstartOFF(allareOFFofautomaticsynchronousstart,manualsynchronousstart)
Ifitcarriesoutexceptfuture,itwilldisplayanerrorandwillbecomeacontrolstop.
z Ifitsetsupinadditiontothesettingrange,itstopscontrolanddisplaysanerror.
Pleasechangeintotherightsetvalue.
4.Maintenance,check,andtherepairmethod
Pleaseperformmaintenanceandcheckperiodicallyafterconsultinganinstructionmanual.
Iftroubleisdiscovered,pleasecheckinatroubleshooting.
Introuble,pleasecontactthedistributingagentthatpurchased.
