Daiichi Electronics ASY-96 - Setting Method

ASY‑206‑077
13
7.5Settingmethod
Settingmustbecarriedoutinreferencetothesettingarrangementasbelow.
Settingmustbecarriedoutatnovoltage(bothofbusvoltageandgeneratorvoltage)orcontrolstartat
“OFF”position(bothofautomaticandmanualsynchronizationstart).“ERROR”(E3)willdisplayatothersetting
conditionandthecontrolwillstop.Resetcanbedoneatnovoltageoratcontrolstart(bothofautomatic
andmanualsynchronizationstart“OFF”).
(Settingarrangement)
Frequencydifferencesetting(ΔF)
Governorpulsewidthsetting(Fpw)
Circuitbreakeradvancetimesetting(25T)
(7segmentLED)：Green
Frequencydifference:Hzdisplay
(7segmentLED)：Green
Voltagedifference:%display
15R：Red,15L：Green
Governorcontrolsignal(2coloredLED)
Voltagecontrolsignal(2coloredLED)
60R：Red,60L：Green
Synchronismchecksignal
±15°：Amber
Circuitbreakerclosingsignal
25：Green
Voltageadjustmentpulsewidthsetting(Vpw)
Voltageadjustmentpulseperiodsetting(Vpint)
Voltagedifferencesetting(ΔV)
Alarmsignal.ALARM：Red
Powersupply.POWER：Green
(SquaretypeLED,26points)
Phasedifference
△F
△V
Hz
％
Withinfrequencydifferencesetting
ΔF：Green
Withinvoltagedifferencesetting
ΔV：Green
(Settingprocedure)
(1)Voltagedifferencesetting(ΔV)(Rotarycordswitch)
Voltagedifferencesetting(ΔV)canbedonebyrotarycordswitchatgivenvalueinreferenceto
thefollowingcodesettingvaluetable.“ERROR”(E3)isdisplayatsetting,cords0.
Cord Voltagedifference(ΔV)setpoint
1 1％
2 2％
3 3％
4 4％
5 5％
6 7％
7 10％
0 ‑
←5％factorysetting
AC110V＝100％
(2)Voltageadjustmentpulsewidthsetting(Vpw)(Rotarycordswitch)
Setatgivenvalueinreferencetocodesettingvaluetableforvoltageadjustmentpulsewithsetting
(Vpw).“ERROR”(E3)isdisplayatsetting,cords0.
Cord Voltageadjustmentpulsewidthsettingpoint(Vpw)
1 0.1s
2 0.2s
3 0.3s
4 0.4s
5 0.5s
6 0.7s
7 1.0s
0 ‑
←0.5sfactorysetting
