ASY‑206‑077
14
(3)Voltageadjustmentpulseperiodsetting(Vpint)(Rotarycordswitch)
Setatgivenvalueinreferencetocodesettingvaluetable.“ERROR”(E3)isdisplayatsetting,code6,7,
and0.
Cord Voltageadjustmentpulseperiodsettingpoint(Vpint)
11s
2 2s
33s
44s
55s
6 ‑
7 ‑
0 ‑
←2sfactorysetting.
(4)Frequencydifferencesetting(ΔF)(Rotarycordswitch).
Setatgivenvalueinreferencetocodesettingvaluetable.“ERROR”(E3)isdisplayatsetting,code6,7,
and0.
Cord Frequencydifferencesettingpoint(ΔF)
1 0.1Hz
2 0.15Hz
3 0.2Hz
4 0.25Hz
5 0.3Hz
6 ‑
7 ‑
0 ‑
←0.1Hzfactorysetting
(5)Governorpulsewidthsetting(Fpw)(Rotarycordswitch).
Setatgivenvalueinreferencetocodesettingvaluetable.“ERROR”(E3)isdisplayatsetting,codes0.

Cord Governorpulsewidth(Fpw)settingpoint
1 0.1s
2 0.2s
3 0.3s
4 0.4s
5 0.5s
6 0.7s
7 1.0s
0 ‑
←0.5sfactorysetting
