FrontCoverPressureSwitchTube
Step4
 Locatethe24”x¼”
squaretubeinparts/
“drainassemblybag”
thatisshippedwith
furnace.
 Installoneendon
thefrontcover
pressureswitch,and
theotherendonto
thebottom/lower
collectorboxport.
Attachtolower
collectorboxport
©2014DaikinNorthAmerica,LLC
FrontCoverPressureSwitchTube
Step5
 Cutoffaccess
tubing,andtuck
accesshoseintothe
furnace
compartmentclose
totheinducerdraft
motor.
