Daikin 90 Plus AFUE - Horizontal Left Side Down Installation; Hose Clamps and Plug Removal; Hose #6 Cutting for Cabinet Width

16
©2014DaikinNorthAmerica,LLC
HorizontalLeftSideDown
 Removethehoseclamps,two
screwsthatholdthetraponto
blowerdeckinpriorprocedure.
 Removethetwoplugsfromthe
leftsideofthecabinetandre‐
installintheblowerdeck.
 Locatehose#6.Measuringfrom
thenon‐grommetend,cutoff
anddiscard:
Hose#6
1½“fora
“D”width
cabinet
8½“fora
“B”width
cabinet
5”fora
“C”width
cabinet
©2014DaikinNorthAmerica,LLC
D M 97 M C 080 3 B N A A
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Brand MinorRevision
D‐ Daikin A‐ InitialRelease
B‐ 1stRevision
Configuration
M‐ Upflow/Horizontal
C‐ Downflow/Horizontal
MajorRevision
A‐ InitialRelease
AFUE
B‐ 1stRevision
97‐ 97%AFUE
GasValve NOx
M‐ Modulating N‐ LowNOx
V‐ 2Stage
H‐ Convertible2Stage
S‐ SingleStage
CabinetWidth
A‐ 14"
Motor
B‐ 17.5"
C‐ VariableSpeedECM/ComfortNet C‐ 21"
E‐ Multi‐SpeedECM D‐ 24.5"
S‐ SingleSpeed
MBTU/h MaximumCFM
040‐ 40,000BTU/h 2‐ 800CFM
120‐ 120,000BTU/h 3‐ 1200CFM
4‐ 1600CFM
5‐ 2000CFM
FurnaceCabinetDimensions
Lookatmodelnumberofyourfurnace.(11
th
place)
