Daikin 90 Plus AFUE - Left Side Drain Hose Connections

17
©2014DaikinNorthAmerica,LLC
HorizontalLeftSideDown
 Removetherubber
plugfromthevent‐
drainelbowside
port.
Remove
Plug
©2014DaikinNorthAmerica,LLC
HorizontalLeftSideDown
 Placehose#6onthe
vent‐drainelbow
sideportandsecure
withasilverclamp.
 Removeblackdrain
capnearthelower
collectorboxport,
andplaceonbarbed
fitting.
 Securewithared
clamp.
Attachtovent‐drain
elbowsideport
Blackcap
securedwith
redclamp
