Daikin 90 Plus AFUE - Page 19

18
©2014DaikinNorthAmerica,LLC
HorizontalLeftSideDown
 Locatehose#5andcut
3”fromthenon‐
grommetend.
 Insertthecutendof
hose#5throughthe
lowercabinetdrainhole
furthestfromthetopof
thefurnace.(insertfrom
theoutsideofcabinetin)
 Connecthose#5&#6
usingthe100degree
elbow,(indr
ainassembly
bag)andsecur
ewithtwo
redclamps.
Cut3”fromthenon‐
gromett end
100degree
elbow
©2014DaikinNorthAmerica,LLC
HorizontalLeftSideDown
 Drainthecollector
box.
 Installthenon‐
grommetendofhose
#11fromtheinsideof
thecabinet,intothe
cabinetholeclosestto
thetop/airdischarge
endofthefurnace.
 Installoncollectorbox
andsecurewithasilver
clamp.
 Usetwosilv erclamps
andsecurethehoses
tothedr
aintr
ap.
