Daikin 90 Plus AFUE - Venting Procedures; Direct vs. Non-Direct Venting

19
©2014DaikinNorthAmerica,LLC
 Suspension,Leveling,Filters,ReturnOptions
 CondensateDrainTrap,DrainPan,andLines
 HorizontalRightSideDown
 HorizontalLeftSideDown
 Venting
 GasValveandConnections
 ElectricalConnections
 24VoltThermostatWiring
 ComfortNet
 FurnaceStartUp
 TemperatureRiseandBlowerSpeedAdjust
 DuctStatic
Agenda
©2014DaikinNorthAmerica,LLC
 Allfurnacesaredualcertified,and
builtwitha2”vent/intakepipe
andconnectors.
 Transitioningfrom2”to3”PV C
pipeshouldbedoneascloseto
thefurnaceaspossible.
 DonotconnecttoTypeB,BW,or
Lventoranyventconnector.
(metal)
 Mustnotbeve
ntedtoan
y
portionofafactorybuilt,or
masonrychimney exceptwhen
usedasapathwayforPVCtopass
through.
DirectorNon‐DirectVenting
