Daikin Altherma HT - Inverter PCB - A4 P

PCB Layout for EKHBRD 011/014/016 AA/AB/AC/AD V1/Y1 ESIE09-08B
36 Refrigerant Circuit
2.3 Inverter PCB - A4P
Inverter PCB - single phase
white
X32A
red
X17A
blue
X18A
blue
X12A
white
X11A
white
X13A
white
X21A
white
X5A
white
X9A
white
X6A
X106A red X41A blue X107A white X111A white LE white P orange Fuse 1 5A 250V for 111F/112F
X25Ablue X27Apink X28Agrey X77Ayellow
LDorange
X51Ablue
HAP= LED
Fuse 2 6,3A 250V for Y1S/ECHC
red
LC
blue
NC
red
U
white
V
blue
W
grey
N
