BRC1E53 Installer reference guide
4P419250-1
–
2015.10
48
Connection diagram
22-3 Group control: main controller + sub controller
0 1 2
P1 P2
P1 P2 P1 P2
P1 P2 P1 P2
22-4 Group control: controller + digital inputs adapter
BRP7A5*
0 1 2
P1 P2
P1
P2
P1 P2
P1 P2 P1 P2
