Menu Options
3
Airflow Direction
Louver2
Louver1
Setting
Position 0 Position 0
When front/back
direction is selected
Airflow Direction
Setting
Position 0Position 0
Louver2
Louver1
When left/right
direction is selected
(2) Adjusting method for selecting dual
airfl ow directions.
Press Ɣ
buttons, to select front/back
or left/right direction setting.
These operation and screen are example of
dual airfl ow directions type indoor unit
(Single fl ow cassette model).
Notice
4
Airflow Direction
Setting
Position 0 Position 0
Louver2
Louver1
Airflow Direction
Setting
Swing Position 0
Louver2
Louver1
Airflow Direction
Setting
SwingSwing
Louver2
Louver1
Select the desired airfl ow direction Ɣ
from Position 0 , Position 1 , Position 2 ,
Position 3 , Position 4 , Swing or Auto
using buttons.
Selecting Ɣ Swing will cause the airfl ow
direction louver to swing position 0 to 4.
Setting Ɣ Auto is not available when left/
right direction is selected.
Press Ɣ Menu/OK button to confi rm the
settings and return to the basic screen.
5
Room
Fri
11
:
03
A
Set to
74
F
Cool
74 F
Basic screen
(Detailed display)
If dual airfl ow directions are set, then the Ɣ
dual airfl ow direction icons are displayed
in the basic screen.
