Daikin DAR09 - Page 33

33
ACCESSORIES
EXPANSION VALVE KITS
SUCTION LINE
BULB
1/4 FLARE CONNECTION
EXPANSION VALVE
EVAPORATOR COIL
REMOVE BEFORE INSTALLING EXPANSION VALVE
SEAL SUPPLIED W/ KIT
SEAL SUPPLIED W/ KIT
BULB TO BE LOCATED
AT 10 OR 2 O'CLOCK
TAILPIECE
3/8"-
SWEAT
7/8" NUT
DISTRIBUTOR
BODY
PISTON
SEAL
For Applicaons requiring
a eld installed access ng
EVAPORATOR COIL
1/4' FLARE
CONNECTION
BULB
SUCTION LINE
EXPANSION VALVE
REMOVE BEFORE
INSTALLING
EXPANSION VALVE
SEAL SUPPLIED W/ KIT
SEAL SUPPLIED W/ KIT
BULB TO BE LOCATED
AT 10 OR 2 O'CLOCK
TAILPIECE
3/8"-
SWEAT
7/8" NUT
DISTRIBUTOR
BODY
PISTON
SEAL
For Applicaons not requiring
a eld installed access ng
Set Point
Adjustment
Screw
Set Point
Indicator
Mark
(Shown @ Oº F)
Thermostat
Dial
DEAD
DIAL
315º
45º
COLD
(Turn Clockwise)
WARM (Turn Counterclockwise)
OT18-60
OT/EHR18-60
OUTDOOR THERMOSTAT &
EMERGENCY HEAT RELAY
Not for use with
ComfortNet System
