PRODUCT IDENTIFICATION
AIR HANDLERS
A W U
F
3642 1 6 AA
1 2 3 4 5,6,7,8 9 10
11,12
Brand Engineering*
A Airhandler
Unit Application Refrigerant Charge
C Ceiling Mount PSC Motor 4 = R-410a
D
Downflow PSC Motor
E Electrical
1 208/240V, 1 Phase, 60 Hz
R Multi Position PSC Motor
S Mul ti Pos i tion EEM Motor
T Coated Coils
W Wal l Mount PSC/EEM Motor
3636 = 3 Ton
Cabinet Finish 1830 = 1-1/2 - 3-1/2 Tons
U Unpainted 3137 = 3 Tons
P Pa i nted 3642 = 3 - 3-1/2Tons
N Unca s ed
1729 = 3 Ton
Expansion Device
F Flowrator
T Expansion Valve 1803 = 1-1/2 Tons Cooling/3 kW Electric Heat
1805 = 1-1/2 Tons Cooling/5 kW Electric Heat
2405 = 2 Tons Cooling/5 kW Electric Heat
3608 = 3 Tons Cooling/8 kW Electric Heat
3105 = 1-1/2 - 2-1/2 Tons Cooling/5 kW Electric Heat
3210 = 2 - 2-1/2 Tons Cooling/5 kW Electric Heat
3705 = 3 Tons Cooling/5 kW Electric Heat
3708 = 3 Tons Cooling/8 kW Electric Heat
3710 = 3 Tons Cooling/10 kW Electric Heat
An "F" in the model number denotes a
Factory Installed Float Switch is present.
Multi-Position & Downflow Application
(Nominal Cooling Capacity/Electric Heat kW)
Ceing Mount & Wall Mount Applications
@ 13 SEER Dedicated Application
Multi-Position & Downflow Application @10 SEER
Major/Minor Revisions
Nominal Capacity
Multi Position
Vari abl e Speed
Motor
All Airhandlers use DIRECT DRIVE MOTORS. Power supply is AC 208-240v, 60 hz, 1 phase.
