Daikin ERLA03DAV3 - Page 151

10 | Configuration
Installer reference guide
151
ERLA03DAV3 + EHFZ03S18DJ3V
Daikin Altherma 3 R F
4P596821-1B – 2021.10
# Code Description
[A.6.3.1] [4-08] Mode:
▪ 0 (No limitation)(default): Disabled.
▪ 1 (Continuous): Enabled: You can set one
power limitation value (in A or kW) to which
the system power consumption will be
limited for all the time.
▪ 2 (Digital inputs): Enabled: You can set
up to four different power limitation values
(in A or kW) to which the system power
consumption will be limited when the
corresponding digital input asks.
[A.6.3.2] [4-09] Type:
▪ 0 (Current): The limitation values are set in
A.
▪ 1 (Power)(default): The limitation values are
set in kW.
[A.6.3.3] [5-05] Amp. value : Only applicable in case of full
time power limitation mode.
0A~50A, step 1A
[A.6.3.4] [5-09] kW value : Only applicable in case of full time
power limitation mode.
0kW~20kW, step 0.5kW
Amp. limits for DI: Only applicable in case of power limitation mode based
on digital inputs and based on current values.
N/A [5-05] Limit DI1
0A~50A, step 1A
N/A [5-06] Limit DI2
0A~50A, step 1A
N/A [5-07] Limit DI3
0A~50A, step 1A
N/A [5-08] Limit DI4
0A~50A, step 1A
kW limits for DI: Only applicable in case of power limitation mode based on
digital inputs and based on power values.
N/A [5-09] Limit DI1
0kW~20kW, step 0.5kW
N/A [5-0A] Limit DI2
0kW~20kW, step 0.5kW
N/A [5-0B] Limit DI3
0kW~20kW, step 0.5kW
N/A [5-0C] Limit DI4
0kW~20kW, step 0.5kW
