Daikin ERLA16DAV3 - Space Heating;Cooling

11 | Configuration
Installer reference guide
192
ERLA11~16DAV3+W1 + EBVH16SU23DJ
Daikin Altherma 3 R F
4P655196-1 – 2021.09
# Code Description
[3.A] [C‑06] External room thermostat type for the additional
zone:
▪ 1: 1 contact. Connected to only 1 digital
input (X2M/35a)
▪ 2: 2 contacts. Connected to 2 digital inputs
(X2M/34a and X2M/35a)
Leaving water temperature: Delta T
For more information, see "11.6.3Main zone"[4177].
# Code Description
[3.B.1] [1-0C] Delta T heating: A minimum temperature
difference is required for the good operation of
heat emitters in heating mode.
▪ If [2-0D] = 2, this is fixed to 8°C
▪ Else: 3°C~10°C
[3.B.2] [1-0E] Delta T cooling: A minimum temperature
difference is required for the good operation of
heat emitters in cooling mode.
▪ 3°C~10°C
WD curve type
There are 2 methods to define the weather-dependent curves:
▪ 2-points (see "11.5.22-points curve"[4168])
▪ Slope-Offset (see "11.5.3Slope-offset curve"[4169])
In [2.E] WD curve type, you can choose which method you want to use.
In [3.C] WD curve type, the chosen method is shown read-only (same value as in
[2.E]).
# Code Description
[2.E] / [3.C] N/A ▪ 2-points
▪ Slope-Offset
11.6.5 Space heating/cooling
INFORMATION
EBVH16SU23DJ6V is a heating only model. Therefore, all references to cooling in this
document are NOT applicable.
Overview
The following items are listed in the submenu:
