4 | About the box
Installer reference guide
22
ERLA11~16DAV3+W1 + EBVH16SU23DJ
Daikin Altherma 3 R F
4P655196-1 – 2021.09
4 About the box
INFORMATION
EBVH16SU23DJ6V is a heating only model. Therefore, all references to cooling in this
document are NOT applicable.
In this chapter
4.1 Overview: About the box........................................................................................................................................................ 22
4.2 Outdoor unit ........................................................................................................................................................................... 22
4.2.1 To handle, unpack and remove accessories – Outdoor unit................................................................................. 22
4.2.2 To remove the transportation stay........................................................................................................................ 24
4.3 Indoor unit .............................................................................................................................................................................. 25
4.3.1 To unpack the indoor unit...................................................................................................................................... 25
4.3.2 To remove the accessories from the indoor unit.................................................................................................. 25
4.3.3 To handle the indoor unit ...................................................................................................................................... 26
4.4 Domestic hot water tank kit ................................................................................................................................................... 26
4.4.1 To remove the accessories from the domestic hot water tank kit ....................................................................... 26
4.5 Checklist for the required DHW accessories.......................................................................................................................... 27
4.1 Overview: About the box
This chapter describes what you have to do after the boxes with the outdoor and
indoor unit are delivered on-site.
Keep the following in mind:
▪ At delivery, the unit MUST be checked for damage. Any damage MUST be
reported immediately to the claims agent of the carrier.
▪ Bring the packed unit as close as possible to its final installation position to
prevent damage during transport.
▪ Prepare the path along which you want to bring the unit inside in advance.
4.2 Outdoor unit
4.2.1 To handle, unpack and remove accessories – Outdoor unit
CAUTION
To avoid injury, do NOT touch the air inlet or aluminium fins of the unit.
1 To handle the unit before unpacking, use a forklift or pallet truck.
