Specifications 6
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXM18PVMK FTXM24PVMK
Outdoor Unit
RXM18PVMK RXM24PVMK
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 5.28 (1.7 ~ 6.0) 5.42 (1.0 ~ 5.4) 7.03 (1.9 ~ 8.6) 6.33 (1.1 ~ 6.3)
Btu/h 18,000 (5,700 ~ 20,500) 18,500 (3,500 ~18,500) 24,000 (6,500 ~ 29,500) 21,600 (3,700 ~ 21,600)
kcal/h 4,540 (1,440 ~ 5,170) 4,660 (890 ~ 4,660) 6,050 (1,640 ~ 7,430) 5,440 (930 ~ 5,440)
Moisture Removal L/h 2.9 — 4.5 —
Running Current (Rated) A 6.4 - 6.1 - 5.8 / 6.4 - 6.1 5.9 - 5.6 - 5.4 / 5.9 - 5.6 8.8 - 8.4 - 8.1 / 8.8 - 8.4 7.2 - 6.9 - 6.6 / 7.2 - 6.9
Power Consumption
Rated (Min. ~ Max.)
W 1,350 (300 ~ 1,700) 1,250 (240 ~ 1,250) 1,890 (350 ~ 2,600) 1,540 (280 ~ 1,540)
Power Factor (Rated) %
95.9 - 96.2 - 97.0 /
95.9 - 96.2
96.3 - 97.0 - 96.5 /
96.3 - 97.0
97.6 - 97.8 - 97.2 /
97.6 - 97.8
97.2 - 97.0 - 97.2 /
97.2 - 97.0
COP
Rated (Min. ~ Max.)
W/W 3.91 (5.57 ~ 3.54) 4.34 (4.29 ~ 4.34) 3.72 (5.46 ~ 3.32) 4.11 (3.86 ~ 4.11)
Piping
Connections
Liquid mm φ 6.4 φ 6.4
Gas mm φ 12.7 φ 12.7
Drain mm φ 16.0 φ 16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTXM18PVMK FTXM24PVMK
Front Panel Color (Mancel No.) White (N95) White (N95)
Airflow Rate
H
m³/min
(cfm)
20.5 (724) 22.2 (784) 22.0 (777) 22.9 (809)
M 16.5 (583) 17.5 (618) 17.7 (625) 17.7 (625)
L 12.6 (445) 13.4 (473) 13.7 (484) 13.8 (487)
SL 10.9 (385) 11.7 (413) 12.2 (431) 12.0 (424)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 48 48
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A
0.45 - 0.43 - 0.41 /
0.45 - 0.43
0.49 - 0.47 - 0.45 /
0.49 - 0.47
0.70 - 0.67 - 0.64 /
0.70 - 0.67
0.70 - 0.67 - 0.64 /
0.70 - 0.67
Power Consumption (Rated) W 59 65 85 85
Power Factor (Rated) %
59.6 - 59.7 - 60.0 /
59.6 - 59.7
60.3 - 60.1 - 60.2 /
60.3 - 60.1
55.2 - 55.2 - 55.3 /
55.2 - 55.2
55.2 - 55.2 - 55.3 /
55.2 - 55.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,050 × 259 340 × 1,050 × 259
Packaged Dimensions (H × W × D) mm 342 × 1,160 × 429 342 × 1,160 × 429
Weight (Mass) kg 15 15
Gross Weight (Gross Mass) kg 21 21
Sound
Pressure
Level
H / M / L / SL dB(A) 48 / 42 / 35 / 32 50 / 42 / 34 / 31 51 / 45 / 37 / 34 51 / 43 / 35 / 32
Outdoor Unit RXM18PVMK RXM24PVMK
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC40BXD 2YC40BXD
Motor Output W 1,300 1,300
Refrigerant
Oil
Type FW68DA FW68DA
Charge L 0.650 0.650
Refrigerant
Type R-32 R-32
Charge kg 1.12 1.40
Airflow Rate
H
m³/min
(cfm)
76.9 (2,715) 49.8 (1,758) 74.2 (2,620) 62.5 (2,207)
SL 62.0 (2,189) 48.3 (1,705) 61.4 (2,168) 55.3 (1,953)
Fan
Type Propeller Propeller
Motor Output W 128 128
Running Current (Rated) A 6.1 - 5.8 - 5.5 / 6.1 - 5.8 5.6 - 5.3 - 5.1 / 5.6 - 5.3 8.4 - 8.0 - 7.7 / 8.4 - 8.0 6.8 - 6.5 - 6.2 / 6.8 - 6.5
Power Consumption (Rated) W 1,291 1,185 1,805 1,455
Power Factor (Rated) %
96.2 - 96.8 - 97.8 /
96.2 - 96.8
96.2 - 97.2 - 96.8 /
96.2 - 97.2
97.7 - 98.1 - 97.7 /
97.7 - 98.1
97.3 - 97.3 - 97.8 /
97.3 - 97.3
Starting Current A 6.4 8.8
Dimensions (H × W × D) mm 695 × 930× 350 695 × 930× 350
Packaged Dimensions (H × W × D) mm 762 × 1,004 × 475 762 × 1,004 × 475
Weight (Mass) kg 46 49
Gross Weight (Gross Mass) kg 52 56
Sound
Pressure
Level
H dB(A) 51 51 56 55
Drawing No. 3D093401 3D093402
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
7.5 m
