Specifications SiMT041509E
7 Specifications
50 Hz, 220 - 230 - 240 V / 60 Hz, 220 - 230 V
Note:

The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXM28PVMK
Outdoor Unit
RXM28PVMK
Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 8.21 (1.9 ~ 9.4) 6.57 (1.1 ~ 6.6)
Btu/h 28,000 (6,500 ~ 32,000) 22,400 (3,700 ~ 22,400)
kcal/h 7,060 (1,640 ~ 8,070) 5,650 (930 ~ 5,650)
Moisture Removal L/h 5.6 —
Running Current (Rated) A 10.7 - 10.2 - 9.8 / 10.7 - 10.2 8.4 - 8.0 - 7.7 / 8.4 - 8.0
Power Consumption
Rated (Min. ~ Max.)
W 2,310 (310 ~ 3,030) 1,760 (270 ~ 1,760)
Power Factor (Rated) % 98.1 - 98.5 - 98.2 / 98.1 - 98.5 95.2 - 95.7 - 95.2 / 95.2 - 95.7
COP
Rated (Min. ~ Max.)
W/W 3.55 (6.16 ~ 3.10) 3.73 (4.00 ~ 3.73)
Piping
Connections
Liquid mm φ 6.4
Gas mm φ 15.9
Drain mm φ 16.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Unit FTXM28PVMK
Front Panel Color (Mancel No.) White (N95)
Airflow Rate
H
m³/min
(cfm)
25.2 (890) 27.2 (960)
M 20.6 (727) 21.2 (749)
L 16.3 (576) 16.2 (572)
SL 14.5 (512) 14.9 (526)
Fan
Type Cross Flow Fan
Motor Output W 64
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof
Running Current (Rated) A 0.74 - 0.71 - 0.68 / 0.74 - 0.71 0.69 - 0.66 - 0.63 / 0.69 - 0.66
Power Consumption (Rated) W 91 84
Power Factor (Rated) % 55.9 - 55.7 - 55.8 / 55.9 - 55.7 55.3 - 55.3 - 55.6 / 55.3 - 55.3
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 340 × 1,200 × 259
Packaged Dimensions (H × W × D) mm 342 × 1,310 × 429
Weight (Mass) kg 18
Gross Weight (Gross Mass) kg 25
Sound
Pressure
Level
H / M / L / SL dB(A) 54 / 49 / 42 / 39 53 / 45 / 38 / 35
Outdoor Unit RXM28PVMK
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC40BXD
Motor Output W 1,300
Refrigerant
Oil
Type FW68DA
Charge L 0.650
Refrigerant
Type R-32
Charge kg 1.60
Airflow Rate
H
m³/min
(cfm)
79.0 (2,789) 66.8 (2,359)
SL 61.4 (2,168) 55.3 (1,953)
Fan
Type Propeller
Motor Output W 128
Running Current (Rated) A 10.3 - 9.8 - 9.4 / 10.3 - 9.8 8.0 - 7.6 - 7.3 / 8.0 - 7.6
Power Consumption (Rated) W 2,219 1,676
Power Factor (Rated) % 97.9 - 98.4 - 98.4 / 97.9 - 98.4 95.2 - 95.9 - 95.7 / 95.2 - 95.9
Starting Current A 10.7
Dimensions (H × W × D) mm 695 × 930× 350
Packaged Dimensions (H × W × D) mm 762 × 1,004 × 475
Weight (Mass) kg 49
Gross Weight (Gross Mass) kg 56
Sound
Pressure
Level
HdB(A) 57 57
Drawing No. 3D093403
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB / 24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
7.5 m
