Specications
Troubleshooting
Model name MCK70ZVM-W / MCK70ZVM-H
Power supply Single phase 50Hz 220-240V / 60Hz 220-230V
Operation mode
Air Purifying
Humidifying and Air Purifying
(at indoor temp.: 20ºC, indoor humidity: 30%)
Turbo Standard Low Quiet Turbo Standard Low Quiet
Power consumption (W) 82 20 11 10 84 23 12 10
Operating sound (dB) 54 37 27 18 54 37 27 18
Airow rate (m³/h) 420 210 132 84 420 210 132 84
Humidifying rate (mL/h) – *1 700 *2
Coverage area (m²)
48
96
*3
*4
–
CADR (m³/h) 375 *5 –
External dimensions (mm) 760(H)× 315(W)× 315(D)
Weight (kg) 12.5 (when the water tank is empty)
Water tank volume (L) About 3.4 *6
Power supply cord length (m) 2
• These specication values are applicable to both 50Hz 220–240V and
60Hz 220–230V.
• Even when the power is off, about 1W (*7) of power is consumed to run
the microcomputer.
• This appliance is designed to be used in residential or commercial
areas.
• A-weighted emission sound pressure level is below 70dB(A).
*1. When there is water in the water tank, the water may decrease and ambient
humidity may rise slightly.
*2. Humidifying rate was calculated in accordance with JEM1426.
(when FAN setting is “Turbo”)
*3. Coverage area was calculated in accordance with JEM1467.
(when FAN setting is “Turbo”)
*4. Coverage area was calculated in accordance with NRCC-54013 standard
using cigarette smoke CADR.
*5. CADR was tested in accordance with JEM1467.
(when FAN setting is “Turbo”)
*6. When the water tank is lled while installed in the unit. If water tank is
removed from the unit before lling, the water tank volume is 2.5liters in
order to make carrying easier.
*7. If the wireless LAN connection adapter function is “OFF”.
Humidifying rate
(at indoor temp.: 20ºC, indoor humidity: 30%)
Turbo
700
0
Low QuietStandard
Humidifying rate (mL/h)
