spaCe TemperaTure seTpoInT meThods
www.DaikinApplied.com 61 ED 15103-6 • MICROTECH III WSHP UNIT CONTROLLER
Example Setpoint Calculations
The following tables show how to apply the formulas from the
preceding section. Each mode (Occupied, Unoccupied, or
Standby) uses the default values shown in Table 29. Table 30
provides common setpoint scenarios as a helpful reference
when working with temperature setpoint parameters. Table
31 shows which WSHP models apply to each unit type
(HP0-HP3).
Table 29: Temperature Setpoint Defaults
AV1 (nciSetpoints.occupied_cool) =
75°F
AV5 (nciSetpoints.standby_heat) =
66°F
AV2 (nciSetpoints.standby_cool) =
77°F
AV6 (nciSetpoints.unoccupied_heat)
= 60°F
AV3 (nciSetpoints.unoccupied_cool)
= 85°F
AV10 (nciOccDiff) = 1°F
AV4 (nciSetpoints.occupied_heat) =
70°F
AV17 (uciUnoccDiff) = 2°F
Table 30: Example Calculations
Unoccupied
Mode
Occupied Mode
using Network
Setpoints
Occupied Mode
using Long
Range Setpoint
Adjust
Standby Mode
using Short
Range Setpoint
Adjust
Effective Cool ON
SP = 85°F
MSV14
(nciLocSptEnable)
= Disabled
MSV14
(nciLocSptEnable)
= Enabled
MSV14
(nciLocSptEnable)
= Enabled
Effective Cool
OFF SP = (85 – 2)
= 83°F
AV19
(nviSetpoint) =
72°F
Reference SP =
AI5 (nvoSetpoint)
= 72.5°F
HP0/HP1
1
: AV25
(nvoSetptShift)
= 3°F
HP2/HP3
1
: AV24
(nvoSetptShift)
= 3°F
Effective Heat ON
SP = 60°F
AV35
(nviSetptOffset) =
0.5°F
Deadband Factor
= ((75 – 70) / 2)
= 2.5
Effective Cool ON
SP =
(77 + 3) = 80°F
Effective Heat
OFF SP
= (60 + 2) = 62°F
Reference SP
= (72 + 0.5) =
72.5°F
Effective Cool ON
SP =
(72.5 + 2.5) =
75°F
Effective Cool
OFF SP =
(80 – 1) = 79°F
Deadband Factor
= ((75 – 70) / 2)
= 2.5
Effective Cool
OFF SP =
(75 – 1) = 74°F
Effective Heat ON
SP =
(66 + 3) = 69°F
Effective Cool ON
SP = (72.5 + 2.5)
= 75°F
Effective Heat ON
SP = (72.5 – 2.5)
= 70°F
Effective Heat
OFF SP =
(69 + 1) = 70°F
Effective Cool
OFF SP =
(75 – 1) = 74°F
Effective Heat
OFF SP =
(70 + 1) = 71°F
Effective Heat ON
SP = (72.5 – 2.5)
= 70°F
Effective Heat
OFF SP =
(70 + 1) = 71°F
1. See Table 31 for details.
Table 31: Description of WSHP Models
HP0
Ennity Single Stage Compressor models MHC/MHW, CCH/
CCW (5-ton or less), VFC/VFW, LVC/LVW, and VHC/VHF
HP1
Two Speed Compressor, Multi-Fan Speed (Series1) models
C2H/C2W
HP2
SmartSource Single and Two Stage Compressor (Series2)
models GSH/GSV, GTH/GTV, GCV
HP3
Ennity Large Two Compressor (SS2C) models CCH/CCW (6-
ton or greater), and LVC/LVW
