Universal I/O Status Menu
The Universal I/O Status Menu provides diagnostic information
to qualied service personnel. The items listed in this menu
will provide current status information of the Universal inputs
and outputs. If the universal I/O is congured for resistance,
the value will be displayed in 1/10th ohm scale. If the I/O is
congured for mA, the value will be displayed in micro amps
(1 mA = 1000 micro amps). If I/O is congured for voltage, the
value is displayed in 1/1000th volt scale. Example: MCB-X7
(OA Damper analog output) shows a value of 3000, this would
translate into 3 VDC.
Table 41: Universal I/O Status Menu
Item Display Name Default Setting Range Password Level Item Display Name Default Setting Range Password Level
MCB X1= — 0–9999999 2 EMC X1= — 0–9999999 2
MCB X2= — 0–9999999 2 EMC X2= — 0–9999999 2
MCB X3= — 0–9999999 2 EMC X3= — 0–9999999 2
MCB X4= — 0–9999999 2 EMC X4= — 0–9999999 2
MCB X5= — 0–9999999 2 EMC X5= — 0–9999999 2
MCB X6= — 0–9999999 2 EMC X6= — 0–9999999 2
MCB X7= — 0–9999999 2 EMC X7= — 0–9999999 2
MCB X8= — 0–9999999 2 EMC X8= — 0–9999999 2
EMA X1= — 0–9999999 2 EMD X1= — 0–9999999 2
EMA X2= — 0–9999999 2 EMD X2= — 0–9999999 2
EMA X3= — 0–9999999 2 EMD X3= — 0–9999999 2
EMA X4= — 0–9999999 2 EMD X4= — 0–9999999 2
EMA X5= — 0–9999999 2 EMD X5= — 0–9999999 2
EMA X6= — 0–9999999 2 EMD X6= — 0–9999999 2
EMA X7= — 0–9999999 2 EMD X7= — 0–9999999 2
EMA X8= — 0–9999999 2 EMD X8= — 0–9999999 2
EMB X1= — 0–9999999 2 EME X1= — 0–9999999 2
EMB X2= — 0–9999999 2 EME X2= — 0–9999999 2
EMB X3= — 0–9999999 2 EME X3= — 0–9999999 2
EMB X4= — 0–9999999 2 EME X4= — 0–9999999 2
EMB X5= — 0–9999999 2 EME X5= — 0–9999999 2
EMB X6= — 0–9999999 2 EME X6= — 0–9999999 2
EMB X7= — 0–9999999 2 EME X7= — 0–9999999 2
EMB X8= — 0–9999999 2 EME X8= — 0–9999999 2
