HARDWARE SPECIFICATIONS
MT6210 A2L MITIGATION CONTROLDAIKIN APPLIED
18
Hardware Specications
Table 14: Hardware Specications
Subject Description
Power Supply Class II 24VAC 60HZ 6W Input Power ±20%
Transformer Requirements 24VAC/75VA Class II
Operating Temperature -40C to +70°C
Storage Temperature -40°C to +85°C
Humidity 10% RH to 90% RH (Non-Condensing)
ESD Rating +/- 8KV (Installed in Unit)
Power Surge Rating Input Power Surge 2KV compliant to IEC 61000-4-5
Vibration Rating 50grms
Agency Compliance
Automatic Electrical Controls – Part 1: General Requirements [UL 60730-1: 2016 Ed.5+R:18Oct2021] Automatic
Electrical Controls – Part 1: General Requirements [CAN/CSE60730-1:2015 Ed.5+A1;A2]
Device Classication Type 1 Class A Control Class 1 Appliance
Digital Inputs
“Mode Input” (User Activated SPST Toggle switch), “Boot” (User Activated Tactical push button, “Reset” (User Acti-
vated Tactile push button)
Digital Output "Alarm" and "Fault" 0/5VDC (Active low) Binary Outputs
Dry Contacts "Alarm" (2 series redundant N/C contacts) and "Customer" N/O contact 5A @ 250VAC; 3A @ 30VDC
Comm Ports 2 RS485 ports: 1 congured as “Modbus Client” (sensors). 1 congured as “Modbus Server” (unit controller)
Maximum Sensor Load (mA) 300 @ 5VDC
