Check SiBE121135_A
239 Service Diagnosis
8.13 Outdoor Fan System Check
Check No.19
8.14 Capacitor Voltage Check
Check No.21 Before this check, be sure to check the main circuit for short circuit.
With the circuit breaker still on, measure the voltage according to the drawing of the model in
question. Be careful never to touch any live parts.
To prevent electrical shock, use a tester to check that the voltage between P (+) and N (–) is
50 V or less.
The surface of the test points (P, N) may be covered with the coating. Be sure to make firm
contact between the tester probes and the test points.
(R15128)
YES
YES
NO
NO
Check the outdoor unit fan system.
Outdoor unit fan running?
Outdoor unit fan system
functioning.
Go to Check No. 16.
Reconnect the connector.
Fan motor lead wire
connector disconnected?
(R12869)
Multimeter
(DC. voltage range)
N(–) P(+)
Coating
PCB
Tester probe
(R17868)
To Next Page
