Wired Remote Controller SiBE121135_A
71 Printed Circuit Board Connector Wiring Diagram
3.2 BRC1E52A7, BRC1E52B7
Connectors and
Other Parts
PCB Detail
1) P1, P2 Terminal for indoor unit
2) R1T Room temperature thermistor
P2
P1
R1T
2P298037-1
2P298037-2
