SiBE121135_A Cooling Only
Specifications 20
50 Hz, 220 - 230 - 240 V
Model FTXS60GV1B FTXS71GV1B
Rated Capacity 6.0 kW Class 7.1 kW Class
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
16.0 (565) 17.2 (607)
M 13.5 (477) 14.5 (512)
L 11.3 (399) 11.5 (406)
SL 10.1 (357) 10.5 (371)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.19 - 0.18 - 0.17 0.21 - 0.20 - 0.19
Power Consumption (Rated) W 40 - 40 - 40 45 - 45 - 45
Power Factor (Rated) % 95.7 - 96.6 - 98.0 97.4 - 97.8 - 98.7
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 290 × 1,050 × 250 290 × 1,050 × 250
Packaged Dimensions (H × W × D) mm 361 × 1,145 × 364 361 × 1,145 × 364
Weight (Mass) kg 12 12
Gross Weight (Gross Mass) kg 18 18
Sound
Pressure
Level
H / M / L / SL dB(A) 45 / 41 / 36 / 33 46 / 42 / 37 / 34
Sound Power Level dB 61 62
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 12.7 φ 15.9
Drain mm
φ 18.0 φ 18.0
Drawing No. 3D065735A 3D065737A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
