Daikin Super multi NX E Series

Cooling Only SiBE121135_A
23 Specifications
Ceiling Mounted Built-in Type
50 Hz, 220 - 230 - 240 V /
50 Hz, 230 V 60 Hz, 220 V
Model FDBQ25B8V1 FBQ35C8VEB
Rated Capacity 2.5 kW Class 3.5 kW Class
Decoration
Panel
Model — BYBS45DJW1
Color — White
Dimensions (H × W × D) — 55 × 800 × 500
Weight (Mass) kg — 3.5
Airflow Rate
H
m³/min
6.5 16.0
L 5.2 11.0
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 10 140
Speed Steps 2 Steps 2 Steps
Air Filter Resin net with mold resistance Resin net with mold resistance
Dimensions (H × W × D) mm 230 × 652 × 502 300 × 700 × 700
Packaged Dimensions (H × W × D) mm 301 × 753 × 584 325 × 920 × 900
Weight (Mass) kg 17 25
Gross Weight (Gross Mass) kg 18 28
Sound
Pressure
Level
H / L dB(A) 35 / 28 37 / 29
Sound Power
Level
H / L dB 55 / 49 63 / —
Heat Insulation — Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.35
φ
6.35 (Flare)
Gas mm
φ 9.52 φ 9.52
(Flare)
Drain mm O.D.
φ 27.2 VP25 (O.D. φ 32 / I.D. φ 25)
Model FBQ50C8VEB FBQ60C8VEB
Rated Capacity 5.0 kW Class 6.0 kW Class
Decoration
Panel
Model BYBS45DJW1 BYBS71DJW1
Color White White
Dimensions (H × W × D) 55 × 800 × 500 55 × 1,100 × 500
Weight (Mass) kg 3.5 4.5
Airflow Rate
H
m³/min
16.0 18.0
L 11.0 15.0
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 140 350
Speed Steps 2 Steps 2 Steps
Air Filter Resin net with mold resistance Resin net with mold resistance
Dimensions (H × W × D) mm 300 × 700 × 700 300 × 1,000 × 700
Packaged Dimensions (H × W × D) mm 355 × 920 × 900 355 × 1,220 × 900
Weight (Mass) kg 25 34
Gross Weight (Gross Mass) kg 28 41
Sound
Pressure
Level
H / L dB(A) 37 / 29 37 / 29
Sound Power
Level
H / L dB 63 / — 57 / —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.35 (Flare)
φ
6.35 (Flare)
Gas mm
φ 12.7
(Flare)
φ 12.7
(Flare)
Drain mm VP25 (O.D.
φ 32 / I.D. φ 25) VP25 (O.D. φ 32 / I.D. φ 25)
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
