Heat Pump SiBE121135_A
25 Specifications
50 Hz, 230 V
Note: The data are based on the conditions shown in the table below.
Model
3MXS68G2V1B, 3MXS68G3V1B 4MXS68F2V1B, 4MXS68F3V1B
Cooling Heating Cooling Heating
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC45DXD 2YC45DXD
Motor Output W 1,380 1,380
Refrigerant Oil
Model FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Type R-410A R-410A
Charge kg 2.59 2.6
Airflow Rate
H
m³/min
52.7 46.4 52.7 46.4
M 49.4 44.5 49.4 44.5
L 43.5 16.3 43.5 16.3
H
cfm
1,861 1,638 1,861 1,638
M 1,744 1,571 1,744 1,571
L 1,536 576 1,536 576
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current A H: 0.20 / M: 0.16 / L: 0.10 H: 0.16 / M: 0.14 / L: 0.03 H: 0.20 / M: 0.16 / L: 0.10 H: 0.16 / M: 0.14 / L: 0.03
Power Consumption W H: 70 / M: 58 / L: 36 H: 55 / M: 48 / L: 10 H: 70 / M: 58 / L: 36 H: 55 / M: 48 / L: 10
Starting Current A 9.1 8.3
Dimensions (H × W × D) mm 735 × 936 × 300 735 × 936 × 300
Packaged Dimensions (H × W × D) mm 797 × 992 × 390 797 × 992 × 390
Weight (Mass) kg 58 58
Gross Weight (Gross Mass) kg 63 63
Sound Pressure Level dB(A) 48 49 48 49
Sound Power Level dB 61 — 61 —
Piping
Connection
Liquid mm
φ
6.4
×
3
φ
6.4
×
4
Gas mm
φ
9.5
×
1,
φ
12.7
×
2
φ
9.5
×
2,
φ
12.7
×
2
Drain mm
φ
16.0
φ
16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 50 (for Total of Each Room) 60 (for Total of Each Room)
m 25 (for One Room) 25 (for One Room)
Amount of Additional Charge g/m 20 (30 m or more) 20 (30 m or more)
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit) 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units) 7.5 (between Indoor Units)
Drawing No. 3D058720B 3D056404A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling Heating Piping Length
Indoor ; 27°CDB / 19°CWB
Outdoor ; 35°CDB
Indoor ; 20°CDB
Outdoor ; 7°CDB / 6°CWB
5 m
