Daikin Super multi NX E Series User Manual

Heat Pump SiBE121135_A
29 Specifications
50 Hz, 220 - 230 - 240 V
Model
FTXG50JV1BW FTXG50JV1BA
Cooling Heating Cooling Heating
Rated Capacity 5.0 kW Class 5.0 kW Class
Front Panel Color White Brushed Aluminium Panel
Airflow Rate
H
m³/min
(cfm)
10.3 (364) 11.4 (402) 10.3 (364) 11.4 (402)
M 8.5 (300) 9.8 (346) 8.5 (300) 9.8 (346)
L 6.7 (237) 8.1 (286) 6.7 (237) 8.1 (286)
SL 5.7 (201) 7.1 (251) 5.7 (201) 7.1 (251)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.16 - 0.15 - 0.14 0.19 - 0.18 - 0.17 0.16 - 0.15 - 0.14 0.19 - 0.18 - 0.17
Power Consumption (Rated) W 32 - 32 - 32 38 - 38 - 38 32 - 32 - 32 38 - 38 - 38
Power Factor (Rated) % 90.9 - 92.8 - 95.2 90.9 - 91.8 - 93.1 90.9 - 92.8 - 95.2 90.9 - 91.8 - 93.1
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 915 × 155 295 × 915 × 155
Packaged Dimensions (H × W × D) mm 285 × 1,003 × 377 285 × 1,003 × 377
Weight (Mass) kg 11 11
Gross Weight (Gross Mass) kg 15 16
Sound
Pressure
Level
H / M / L / SL dB(A) 44 / 40 / 35 / 32 44 / 40 / 35 / 32 44 / 40 / 35 / 32 44 / 40 / 35 / 32
Sound Power Level dB 60 60 60 60
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 12.7 φ 12.7
Drain mm
φ 18.0 φ 18.0
Drawing No. 3D080642 3D080643
Model
CTXS15K2V1B FTXS20K2V1B
Cooling Heating Cooling Heating
Rated Capacity 1.5 kW Class 2.0 kW Class
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
7.9 (279) 9.0 (318) 8.8 (311) 9.5 (335)
M 6.3 (222) 7.5 (265) 6.7 (237) 7.8 (275)
L 4.7 (166) 6.0 (212) 4.7 (166) 6.0 (212)
SL 3.9 (138) 4.3 (152) 3.9 (138) 4.3 (152)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 16 16
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.19 - 0.18 - 0.17 0.19 - 0.18 - 0.17 0.19 - 0.18 - 0.17 0.19 - 0.18 - 0.17
Power Consumption (Rated) W 40 - 40 - 40 40 - 40 - 40 40 - 40 - 40 40 - 40 - 40
Power Factor (Rated) % 95.7 - 96.6 - 98.0 95.7 - 96.6 - 98.0 95.7 - 96.6 - 98.0 95.7 - 96.6 - 98.0
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 289 × 780 × 215 289 × 780 × 215
Packaged Dimensions (H × W × D) mm 274 × 850 × 346 274 × 850 × 346
Weight (Mass) kg 8 8
Gross Weight (Gross Mass) kg 12 12
Sound
Pressure
Level
H / M / L / SL dB(A) 37 / 31 / 25 / 21 38 / 33 / 28 / 21 40 / 32 / 24 / 19 40 / 34 / 27 / 19
Sound Power Level dB 55 56 58 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ 18.0 φ 18.0
Drawing No. 3D074531A 3D080188
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
