Heat Pump SiBE121135_A
31 Specifications
50 Hz, 220 - 230 - 240 V
Model
FTXS50K2V1B
Cooling Heating
Rated Capacity 5.0 kW Class
Front Panel Color White
Airflow Rates
H
m³/min
(cfm)
11.9 (420) 13.3 (470)
M 9.6 (339) 10.8 (381)
L 7.4 (261) 8.4 (297)
SL 4.5 (159) 5.5 (194)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.15 - 0.14 - 0.14
Power Consumption (Rated) W 26 - 26 - 26 32 - 32 - 32
Power Factor (Rated) % 98.5 - 94.2 - 98.5 97.0 - 99.4 - 95.2
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 298 × 900 × 215
Packaged Dimensions (H × W × D) mm 290 × 977 × 371
Weight (Mass) kg 11
Gross Weight (Gross Mass) kg 15
Sound
Pressure
Level
H / M / L / SL dB(A) 46 / 40 / 34 / 23 47 / 40 / 34 / 24
Sound Power Level dB 60 60
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ 12.7
Drain mm
φ 18.0
Drawing No. 3D080621
Model
FTXS25J2V1B FTXS35J2V1B
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 3.5 kW Class
Front Panel Color White White
Airflow Rate
H
m³/min
(cfm)
10.8 (381) 11.9 (420) 11.4 (403) 12.4 (438)
M 7.9 (279) 9.1 (321) 8.7 (307) 9.5 (335)
L 5.2 (184) 6.4 (226) 5.8 (205) 6.8 (240)
SL 3.7 (131) 5.9 (208) 4.4 (155) 6.0 (212)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09 - 0.08 - 0.08 0.10 - 0.10 - 0.09 0.12 - 0.12 - 0.11 0.13 - 0.13 - 0.12
Power Consumption (Rated) W 18 - 18 - 18 21 - 21 - 21 26 - 26 - 26 28 - 28 - 28
Power Factor (Rated) % 90.9 - 97.8 - 93.8 95.5 - 91.3 - 97.2 98.5 - 94.2 - 98.5 97.9 - 93.6 - 97.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366 289 × 870 × 366
Weight (Mass) kg 9 10
Gross Weight (Gross Mass) kg 13 14
Sound
Pressure
Level
H / M / L / SL dB(A) 41 / 33 / 25 / 22 42 / 35 / 28 / 25 45 / 37 / 29 / 23 45 / 39 / 29 / 26
Sound Power Level dB 57 58 61 61
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ 18.0 φ 18.0
Drawing No. 3D070565A 3D070566A
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
