SiBE121135_A Heat Pump
Specifications 34
50 Hz, 220 - 230 - 240 V
Model
ATXS50G2V1B
Cooling Heating
Rated Capacity 5.0 kW Class
Front Panel Color White
Airflow Rate
H
m³/min
(cfm)
10.2 (360) 11.0 (388)
M 8.6 (305) 9.3 (330)
L 7.0 (246) 7.6 (267)
SL 6.0 (212) 6.7 (236)
Fan
Type Cross Flow Fan
Motor Output W 23
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.12 - 0.12 - 0.11 0.15 - 0.14 - 0.14
Power Consumption (Rated) W 26 - 26 - 26 32 - 32 - 32
Power Factor (Rated) % 98.5 - 94.2 - 98.5 97.0 - 99.4 - 95.2
Temperature Control Microcomputer Control
Dimensions (H × W × D) mm 295 × 800 × 215
Packaged Dimensions (H × W × D) mm 289 × 870 × 366
Weight (Mass) kg 10
Gross Weight (Gross Mass) kg 14
Sound
Pressure
Level
H / M / L / SL dB(A) 43 / 39 / 34 / 31 44 / 39 / 34 / 31
Sound Power Level dB 60 61
Heat Insulation Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
Gas mm
φ 12.7
Drain mm
φ 18.0
Drawing No. 3D081101
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
To Next Page
