SiBE121135_A Function of RA Indoor Unit
Function and Control 78
3-D Airflow Wall Mounted Type: FTXS-J/G, ATXS Series
Alternative repetition of vertical and horizontal swing motions enables uniform air-conditioning of
the entire room. This function is effective for starting the air conditioner.
When the horizontal swing and vertical swing are both set to automatic operation, the airflow
becomes 3-D airflow. The horizontal and vertical swing motions are alternated and the airflow
direction changes in the order shown in the following diagram.
(1): The vertical blades (louvers) move from the right to the left.
(2): The horizontal blades (flaps) move downward.
(3): The vertical blades (louvers) move from the left to the right.
(4): The horizontal blades (flaps) move upward.
COMFORT
AIRFLOW
Operation
Wall Mounted Type
The vertical swing flap is controlled not to blow the air directly at the people in the room.
(R13554)
(1)(2)
(3) (4)
Cooling / Dry Heating
(R11665) (R12181)
AB
FTXG 5° 75°
CTXS, FTXS20/25K 0° 50°
FTXS35-50K 5° 70°
FTXS-J 8° 80°
FTXS-G 5° 55°
ATXS 5° 80°
A
B
