ED34-862 Accessories
FXKQ-MA 157
4
Panel Spacer
If the space above the ceiling is not available for more than 220 mm, use the panel spacer, which enables to install
the unit in 200 mm space.
Specifications
Installation
Precaution at use
1. Be sure to stick insulators on the panel spacer after the panel spacer is assembled.
2. Secure 20 cm height in the space above ceiling.
Contents of Kit
Prior to installation check whether you have the complete kit of parts as shown below including the installation
manual.
Model
Item
KPBJ52F56W KPBJ52F80W
Color White
Dimensions
(mm)
Height 20
Width 1,240 1,440
Depth 800
Materials
Outer Frame : Resin Molding
Thermal Insulation : Foam Polyethylene
Contents
Panel Spacer(1)(2)(3)
Thermal Insulation (1)(2), Screws
Applicable Decoration Panel BYK45FJW1 BYK71FJW1
Applicable Model For Indoor Unit 25~40 Class For Indoor Unit 63 Class
