Daikin VRV III - Accessories

Accessories ED34-862
226 FXSQ-M
11.Accessories
Standard Accessories
FXSQ20~125M
• Screws for fixing panels are attached to decoration panel.
3P086156-7D
Optional Accessories (For Unit)
Note:
∗1 One adaptor for wiring (KRP1B61) per indoor unit is required if installing an electric heater or a natural
evaporating pan type humidifier. An electric heater cannot be used for VRV system cooling only.
∗2 If installing a high filter in the ceiling mounted built-in type, an assembly chamber for either bottom or rear
suction is required.
Name Metal clamp
Paper pattern for
installation
Drain hose
Insulation for
fitting
Sealing pad Screws for duct flanges
Quantity 1 pc. 1 pc. 1 pc. 1 each. 1 each. 1 set
Shape
for gas pipe
for liquid pipe
Large
mid
Name
Washer for hanging
bracket
Clamp
Screws for fixing the
paper pattern for
installation
(Other)
• Operation manual
• Installation manual
• Sealing material (Small 35×150)
Quantity 8 pcs. 6 pcs. 6 pcs.
Shape
No.
Type FXSQ20M
FXSQ25M
FXSQ32M
FXSQ40M
FXSQ50M
FXSQ63M
FXSQ80M
FXSQ100M
FXSQ125M
Item
1
Panel
related
Decoration panel BYBS32DJW1 BYBS45DJW1 BYBS71DJW1 BYBS125DJW1
Access panel KTBJ25K36W KTBJ25K56W KTBJ25K80W KTBJ25K160W
2
∗1
Auxiliary
electric
heater
Model 240V/220V KEA25K32VE KEA25K50VE KEA25K63VE KEA25K100VE KEA25K125VE
Capacity kW 0.75 1.2 1.4 2.1 2.8
3
Filter
related
∗2 High efficiency filter
65%
KAFJ252L36 KAFJ252L56 KAFJ252L80 KAFJ252L160
∗2 High efficiency filter
90%
KAFJ253L36 KAFJ253L56 KAFJ253L80 KAFJ253L160
Long life replacement filter KAFJ251K36 KAFJ251K56 KAFJ251K80 KAFJ251K160
Filter
chamber
For bottom
suction
KAJ25L36D KAJ25L56D KAJ25L80D KAJ25L160D
For rear
suction
KAJ25L36B KAJ25L56B KAJ25L80B KAJ25L160B
4
Air inlet
and air
discharge
outlet
related
Air suction canvas KSA-25K36 KSA-25K56 KSA-25K80 KSA-25K160
Screening door KBBJ25K36 KBBJ25K56 KBBJ25K80 KBBJ25K160
Air suction flange KDJ2507K36 KDJ2507K56 KDJ2507K80 KDJ2507K160
Air discharge adaptor KDAJ25K36A KDAJ25K56A KDAJ25K71A KDAJ25K140A
5
Natural evaporating pan type
humidifier ∗1
KNM25K32V1 KNM25K50V1 KNM25K63V1 KNM25K125V1
FXSQ20
.
25
.
32MVE
FXSQ40
.
50MVE
FXSQ63MVE
FXSQ80
.
100
.
125MVE
6
8
12
16
