Daikin VRV III - Page 17

Capacity Range ED34-862
12 General Information
Indoor Units
Note: FXDQ has following 2 series, as shown below.
FXDQ-PBVET, NBVET: without Drain Pump (For General, Asia: except for EU, China and Australia)
FXDQ-PBVE, NBVE: with Drain Pump
BEV unit is required for FXUQ only.
MA:
RoHS Directive models; Specifications, dimensions and other functions are not changed compared with M type.
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Round Flow)
FXFQ — 25P 32P 40P 50P 63P — 80P 100P 125P ——
VE
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M — 80M — 125M ——
Ceiling Mounted
Cassette Corner
Type
FXKQ — 25MA 32MA 40MA — 63MA ——————
Slim Ceiling Mounted
Duct Type
FXDQ-
PBVE
20PB 25PB 32PB —————————
FXDQ-
PBVET
20PB 25PB 32PB —————————
FXDQ-
NBVE
——— 40NB 50NB 63NB ——————
FXDQ-
NBVET
——— 40NB 50NB 63NB ——————
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M — 80M 100M 125M ——
Ceiling Mounted Duct
Type (Middle and
high static pressure)
FXMQ 20P 25P 32P 40P 50P 63P — 80P 100P 125P ——
Ceiling Mounted
Duct Type
FXMQ —————————— 200MA 250MA
Ceiling Suspended
Type
FXHQ — — 32MA —— 63MA —— 100MA ———
Wall Mounted Type
FXAQ 20MA 25MA 32MA 40MA 50MA 63MA ——————
Floor Standing Type
FXLQ 20MA 25MA 32MA 40MA 50MA 63MA ——————
Concealed Floor
Standing Type
FXNQ 20MA 25MA 32MA 40MA 50MA 63MA ——————
Ceiling Suspended
Cassette Type
FXUQ —————— 71MA — 100MA 125MA —— V1
Connection Unit for
FXUQ
BEVQ —————— 71MA — 100MA 125MA —— VE
