Daikin VRV III - Page 208

ED34-862 Features
FXSQ-M 203
6
Example of Installation (Built-In)
 Direct installation of half panel
 Installation of Half panel and suction canvas
 Installation like ceiling mounted cassette type with High efficiency filter
 Installation with duct (A)
Model
FXSQ20M
FXSQ25M
FXSQ32M
FXSQ40M
FXSQ50M
FXSQ63M
FXSQ80M
FXSQ100M
FXSQ125M
Necessary
Options
Remote Controller BRC1C62
Half Panel
BYBS32DJW1 BYBS45DJW1 BYBS71DJW1
BYBS125DJW1
Model
FXSQ20M
FXSQ25M
FXSQ32M
FXSQ40M
FXSQ50M
FXSQ63M
FXSQ80M
FXSQ100M
FXSQ125M
Necessary
Options
Remote Controller BRC1C62
Half Panel
BYBS32DJW1 BYBS45DJW1 BYBS71DJW1 BYBS125DJW1
Air Suction Canvas KSA-25K36 KSA-25K56 KSA-25K80 KSA-25L160
Model
FXSQ20M
FXSQ25M
FXSQ32M
FXSQ40M
FXSQ50M
FXSQ63M
FXSQ80M
FXSQ100M
FXSQ125M
Necessary
Options
Remote Controller BRC1C62
Half Panel
BYBS32DJW1 BYBS45DJW1 BYBS71DJW1 BYBS125DJW1
High
Efficiency
Filter
NBS65% KAFJ252L36 KAFJ252L56 KAFJ252L80 KAFJ252L160
NBS90% KAFJ253L36 KAFJ253L56 KAFJ253L80 KAFJ253L160
Air Suction Canvas KSA-25K36 KSA-25K56 KSA-25K80 KSA-25L160
Bottom Suction Filter
Chamber
KAJ25L36D KAJ25L56D KAJ25L80D KAJ25L160D
The access panel should be fitted beneath the main
body of the unit.
Model
FXSQ20M
FXSQ25M
FXSQ32M
FXSQ40M
FXSQ50M
FXSQ63M
FXSQ80M
FXSQ100M
FXSQ125M
Necessary
Options
Remote Controller BRC1C62
Access Panel KTBJ25K36W KTBJ25K56W KTBJ25K80W
KTBJ25K160W
Rear Suction Filter
Chamber
KAJ25L36B KAJ25L56B KAJ25L80B KAJ25L160B
Screening Door KBBJ25K36 KBBJ25K56 KBBJ25K80 KBBJ25K160
High
Efficiency
Filter (If
Necessary)
NBS65% KAFJ252L36 KAFJ252L56 KAFJ252L80 KAFJ252L160
NBS90% KAFJ253L36 KAFJ253L56 KAFJ253L80 KAFJ253L160
