Specifications ED34-862
206 FXSQ-M
Ceiling Mounted Built-In Type
Note:
∗1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗3 External static pressure is changeable to change over the connectors inside electrical box, this pressure means
“High static pressure-Standard -Low static pressure”.
4 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
∗5 Anechoic chamber conversion value, measured at a point 1.5 m downward from the unit center. These values are normally somewhat higher
during actual operation as a result of ambient conditions.
6 Refer to page 218 for Fan Motor Input.
Model FXSQ40MVE FXSQ50MVE FXSQ63MVE
∗1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000 6,300
Btu/h 16,000 19,800 24,900
kW 4.7 5.8 7.3
∗2 Cooling Capacity (19.0°CWB) kW 4.5 5.6 7.1
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 300×700×800 300×700×800 300×1,000×800
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.75 3×14×1.75 3×14×1.75
Face Area m² 0.132 0.132 0.221
Fan
Model D18H2A D18H2A 2D18H2A
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number of
Units
W 65×1 85×1 125×1
Air Flow Rate (H/L)
m³/min 11.5/9 15/11 21/15.5
cfm 406/318 530/388 741/547
∗3 External Static Pressure Pa 88-49-20 88-59-29 88-49-20
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm
φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
VP25
(External Dia. 32 Internal Dia. 25)
Machine Weight (Mass) kg 30 31 41
∗5 Sound Level (H/L) (220V) dBA 38/32 41/36 42/35
Safety Devices
Fuse.
Thermal Protector for Fan Motor.
Fuse.
Thermal Protector for Fan Motor.
Fuse.
Thermal Protector for Fan Motor.
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R-410A PA Series R-410A PA Series R-410A PA Series
Decoration
Panel
(Option)
Model BYBS45DJW1 BYBS45DJW1 BYBS71DJW1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 55×800×500 55×800×500 55×1,100×500
Weight kg 3.5 3.5 4.5
Standard Accessories
Operation Manual. Installation
Manual. Paper Pattern for Installation.
Drain Hose. Clamp Metal. Insulation
for Fitting. Sealing Pads. Clamps.
Screws. Washers.
Operation Manual. Installation
Manual. Paper Pattern for Installation.
Drain Hose. Clamp Metal. Insulation
for Fitting. Sealing Pads. Clamps.
Screws. Washers.
Operation Manual. Installation
Manual. Paper Pattern for Installation.
Drain Hose. Clamp Metal. Insulation
for Fitting. Sealing Pads. Clamps.
Screws. Washers.
Drawing No. C : 3D039431
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
