Accessories ED34-862
228 FXSQ-M
Access Panel
Specifications
Installation
[Before installation]
1. Make an opening on the ceiling
2. Install ceiling joist supports to fit the ceiling opening
[Installation of the ceiling board]
The ceiling board can be installed into the inner frame assembly as follows.
1. Remove decoration panel retainer from the inner frame assembly.
2. Remove the decoration panel and substitute with the ceiling board.
3. Set the ceiling board by retainer removed in step 1 of above.
CAUTION
When the ceiling board is installed, the decoration panel is not needed.
Model
Item
KTBJ25K36W KTBJ25K56W KTBJ25K80W KTBJ25K160W
Color White
Applicable Model 20~32 Class 40 · 50 Class 63 Class 80~125 Class
Dimension
Model A
KTBJ25K36W 626
KTBJ25K56W 776
KTBJ25K80W 1076
KTBJ25K160W 1476
Model A
KTBJ25K36 606
KTBJ25K56 756
KTBJ25K80 1056
KTBJ25K160 1406
