6.7.2 Structure
VAM150GJVE, VAM250GJVE, VAM350GJVE, VAM500GJVE, VAM650GJVE, VAM800GJVE, VAM1000GJVE
3P034927-5J
VAM1500GJVE, VAM2000GJVE
3P034927-5J
SA
(Supply air)
[Feed air to room]
RA
(Return air)
[Exhaust air from room]
OA
(Outdoor air)
[Fresh air from outdoor]
EA
(Exhaust air)
[Exhaust air to outdoor]
(1) Hanger bracket
(2) Duct connecting flange
(3) Exhaust fan
(5) Damper
(4) Air filter (Long life filter)
(8) Heat exchange elements
(11) Remote controller
(Optional accessory)
(7) Maintenance cover
(6) Control box
(10) Air supply fan
SA
(Supply air)
[Feed air to room]
RA
(Return air)
[Exhaust air from room]
OA
(Outdoor air)
[Fresh air from outdoor]
EA
(Exhaust air)
[Exhaust air to outdoor]
