Specifications ED34-862
364 FXLQ-MA / FXNQ-MA
Concealed Floor Standing Type
Note:
∗1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
∗4 Anechoic chamber conversion value, measured at a point 1.5 m in front of the unit at a height of 1.5 m. During actual operation, these values
are normally somewhat higher as a result of ambient conditions.
5 Refer to page 373 for Fan Motor Input.
Model FXNQ40MAVE FXNQ50MAVE FXNQ63MAVE
∗1 Cooling Capacity (19.5°CWB)
kcal/h 4,000 5,000 6,300
Btu/h 16,000 19,800 24,900
kW 4.7 5.8 7.3
∗2 Cooling Capacity (19.0°CWB) kW 4.5 5.6 7.1
Casing Color Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 610×1,070×220 610×1,350×220 610×1,350×220
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×14×1.5 3×14×1.5 3×14×1.5
Face Area m² 0.200 0.282 0.282
Fan
Model 2D14B13 2D14B20 2D14B20
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 25×1 35×1 35×1
Air Flow Rate (H/L)
m³/min 11/8.5 14/11 16/12
cfm 388/300 494/388 565/424
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber / Urethane Foam Glass Fiber / Urethane Foam Glass Fiber / Urethane Foam
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm
φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm
φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride)
Machine Weight (Mass) kg 23 27 27
∗4 Sound Level (H/L) (220V) dBA 38/33 39/34 40/35
Safety Devices
Fuse.
Thermal Protector for Fan Motor.
Fuse.
Thermal Protector for Fan Motor.
Fuse.
Thermal Protector for Fan Motor.
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R-410A PA Series R-410A PA Series R-410A PA Series
Standard Accessories
Operation Manual. Installation
Manual. Insulation for Fitting. Drain
Hose. Clamps. Screws. Washers.
Level Adjustment Screw.
Operation Manual. Installation
Manual. Insulation for Fitting. Drain
Hose. Clamps. Screws. Washers.
Level Adjustment Screw.
Operation Manual. Installation
Manual. Insulation for Fitting. Drain
Hose. Clamps. Screws. Washers.
Level Adjustment Screw.
Drawing No. C : 3D038817A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
