Specifications ED34-862
50 FXFQ-P
Ceiling Mounted Cassette (Round Flow) Type
Note:
∗1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
∗2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5 m, level difference : 0 m.
3 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
∗4 Anechoic chamber conversion value, measured at a point 1.5 m downward from the unit centre. During actual operation, these values are
normally somewhat higher as a result of ambient conditions.
5 Refer to page 56 for Fan Motor Input.
Model FXFQ63PVE FXFQ80PVE FXFQ100PVE FXFQ125PVE
∗
1 Cooling Capacity (19.5°CWB)
kcal/h 6,300 8,000 10,000 12,500
Btu/h 24,900 31,700 39,600 49,500
kW 7.3 9.3 11.6 14.5
∗
2 Cooling Capacity (19.0°CWB) kW 7.1 9.0 11.2 14.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 246×840×840 246×840×840 288×840×840 288×840×840
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×10×1.2 2×10×1.2 2×12×1.2 2×12×1.2
Face Area m² 0.446 0.446 0.535 0.535
Fan
Model QTS48C15M QTS48C15M QTS48C15M QTS48C15M
Type Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W 56×1 56×1 120×1 120×1
Air Flow Rate (HH/H/L)
m³/min 19/16.5/13.5 21/18/15 32/26/20 33/28/22.5
cfm 671/583/477 742/636/530 1,130/918/706 1,165/989/794
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Polyurethane Form Polyurethane Form Polyurethane Form Polyurethane Form
Piping
Connections
Liquid Pipes mm
φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Mass (Weight) kg 22 22 25 25
∗
4 Sound Level (HH/H/L) (220-240V) dBA 34/31/28 36/33.5/31 43/37.5/32 44/39/34
Safety Devices Fuse Fuse Fuse Fuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R-410A VRV PA Series R-410A VRV PA Series R-410A VRV PA Series R-410A VRV PA Series
Decoration
Panels
(Option)
Model BYCP125K-W1 BYCP125K-W1 BYCP125K-W1 BYCP125K-W1
Panel Color Fresh White Fresh White Fresh White Fresh White
Dimensions: (H×W×D) mm 50×950×950 50×950×950 50×950×950 50×950×950
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 5.5 5.5 5.5 5.5
Standard Accessories
Operation Manual.
Installation Manual.
Paper Pattern for
Installation.
Drain Hose. Clamp Metal.
Washer Fixing Plate.
Sealing Pads. Clamps.
Screws. Washer for
Hanging Bracket. Insulation
for Fitting.
Installation Guide.
Operation Manual.
Installation Manual.
Paper Pattern for
Installation.
Drain Hose. Clamp Metal.
Washer Fixing Plate.
Sealing Pads. Clamps.
Screws. Washer for
Hanging Bracket. Insulation
for Fitting.
Installation Guide.
Operation Manual.
Installation Manual.
Paper Pattern for
Installation.
Drain Hose. Clamp Metal.
Washer Fixing Plate.
Sealing Pads. Clamps.
Screws. Washer for
Hanging Bracket. Insulation
for Fitting.
Installation Guide.
Operation Manual.
Installation Manual.
Paper Pattern for
Installation.
Drain Hose. Clamp Metal.
Washer Fixing Plate.
Sealing Pads. Clamps.
Screws. Washer for
Hanging Bracket. Insulation
for Fitting.
Installation Guide.
Drawing No. C : 3D060255
( )( )( )( )
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
